Function effect of stable device operation by solving problems of lightning strike, surge, grounding of high-tech electric-electronic communication information cilities
Grounding function of communication facilities, signal facilities installed in building or container which have little influence from direct strike of lightning
Product code Product name Standard Voltage
/breaker		 Place to use
39121613-21109982 TM-DC-01-1M DC / 12V / 40KA / 1MJ 12V / 30A Device scale Small
39121613-21084434 TM-DC-02-2M DC / 24V / 40KA / 2MJ 24V / 30A Device scale Small
39121613-21084435 TM-DC-04-5M DC / 48V / 40KA / 5MJ 48V / 30A Device scale Small
39121613-21084436 TM-12-10-10M 1Ø2w / 110V / 80KA / 10MJ 110V / 50A Device scale Small
39121613-21084437 TM-12-20-20M 1Ø2w / 220V / 80KA / 20MJ 220V / 75A Device scale Medium
39121613-21084438 TM-34-20-50M 3Ø4w / 380V / 80KA / 50MJ 380V / 100A Device scale Large
  • Voltage / breaker : Voltage is operation power voltage, breaker A indicates main power breaker capaity of swichboard in facility room to be protected
    example : 110V / 30A indicates that operation power voltage -110V and the capacity of switchboard main breaker in the place to install eca3G is 30A
  • MJ (Mega joule) : work energy(Joule) = P×Dt = resistance × current2 × time
